CRANKCASE INSTALLATION
● Install the dowel pins and a new gasket.
● Install the cam chain to the LH. crankcase.
● Install the RH. crankcase to the LH. crankcase.
NOTE
·Make sure that the gasket is completely attached
without any clearance.
● Install the RH./LH. radiator hose.
● Install the bleeder tube to the LH. crankcase.
● Install the removed parts.
● Install the engine on the frame.(⇨6-2 )
11-10
TRANSMISSION/CRANKSHAFT/CRANK CASE
