RADIATOR
REMOVAL
●Remove the front cover. (⇨4-3)
●Remove the front wheel. (⇨12-5)
●Loosen the 2 oil bolts and the 4 drain cock packings
from the main pipe bracket.
●Loosen the 3 flange bolts securing the radiator.
●Remove the radiator.
CAUTION
•Be careful not to damage the radiator when removing it.
•Pay attention not to turn over the vehicle.
INSPECTION
●Check the oil line connections for leaks.
●Check the oil cooler for bent or collapsed fins.
Straighten the bent or collapsed fins with a suitable,
small, blade-type screw driver if necessary.
●Check the air passages for clogging or restriction. Blow
dirt out from between core fins with compressed air or
wash off dirt with water.
●After installing, start the engine and check for leak. Stop
the engine and check the oil level.
2-7
LUBRICATION
