1268 Configuring DHCPv6 Server and Relay Settings

Configuring the DHCPv6 Server and Relay (Web)

This section provides information about the OpenManage Switch

Administrator pages for configuring and monitoring the DHCPv6 server on a

Dell Networking N2000, N3000, and N4000 series switches. For details about

the fields on a page, click at the top of the page.

DHCPv6 Global Configuration

Use the Global Configuration

page to configure DHCPv6 global parameters.

To display the page, click Routing

→

IPv6

→

DHCPv6 Server

→

Global

Configuration in the navigation panel.

Figure 39-2. DHCPv6 Global Configuration

Default Chapter1
