Dell N3000 Series User Manual

Managing IPv4 and IPv6 Multicast 1357
Configuring General IPv4 Multicast Features
(Web)
This section provides information about the OpenManage Switch
Administrator pages for configuring and monitoring the L3 multicast features
that are not protocol-specific on a Dell Networking N2000, N3000, and
N4000 series switches. For details about the fields on a page, click at the
top of the page.
Multicast Global Configuration
Use the Global Configuration page to configure the administrative status of
Multicast Forwarding in the router, and to display global multicast
parameters.
To display the page, click IPv4 Multicast
→ Multicast → Global
Configuration in the navigation panel.
Figure 43-9. Multicast Global Configuration

Dell N3000 Series Specifications

General

Managed	Yes
Stacking Ports	2 x 10GbE SFP+
Weight	12.3 lbs (5.6 kg)
Operating Temperature	32° to 113°F (0° to 45°C)
Ports	24 or 48 10/100/1000 ports
