Dell N3000 Series User Manual

Setting Basic Network Information 155
Route Entry Configuration (Switch Default Gateway)
Use the Route Entry Configuration page to configure the default gateway for
the switch. The default VLAN uses the switch default gateway as its default
gateway. The switch default gateway must not be on the same subnet as the
OOB management port, as the OOB management port cannot route packets
received on the front-panel ports.
To display the Route Entry Configuration page, click Routing
→ Router →
Route Entry Configuration in the navigation panel.
Figure 7-3. Route Configuration (Default VLAN)
NOTE: You do not need to configure any additional fields on the page. For
information about VLAN routing interfaces, see "Configuring Routing Interfaces"
on page 1021.

Dell N3000 Series Specifications

General

Managed	Yes
Stacking Ports	2 x 10GbE SFP+
Weight	12.3 lbs (5.6 kg)
Operating Temperature	32° to 113°F (0° to 45°C)
Ports	24 or 48 10/100/1000 ports
