Dell N3000 Series User Manual

Configuring Port-Based Traffic Control 791
Configuring Port-Based Traffic Control (Web)
This section provides information about the OpenManage Switch
Administrator pages to use to control port-based traffic on a Dell Networking
N2000, N3000, and N4000 series switches. For details about the fields on a
page, click at the top of the page.
Flow Control (Global Port Parameters)
Use the Global Parameters page for ports to enable or disable flow control
support on the switch.
To display the Global Parameters page, click Switching
→ Ports → Global
Parameters in the navigation menu.
Figure 24-1. Global Port Parameters

Dell N3000 Series Specifications

General

Managed	Yes
Stacking Ports	2 x 10GbE SFP+
Weight	12.3 lbs (5.6 kg)
Operating Temperature	32° to 113°F (0° to 45°C)
Ports	24 or 48 10/100/1000 ports
