3. Commissioning
3.6 Automatic booting of the memory card
3.6.3 Preparing the card for booting on the easyE4 device itself
Prerequisites
l
The microSD memory card must contain at least one compiled PRG program.
The easyE4 device must be in STOP mode before it can be configured. If it is not, the
device will point this out.
Insert the memory card while the device is de-energized.
Switch on the supply voltage.
Go to the main menu.
Open the CARD menu option.
STOP ✓ RUN
PARAMETERS
SET CLOCK
CARD
INFORMATION
SYSTEM OPTIONS
PROGRAM
Tab. 11: Main menu
Go to PROGRAM
PROGRAM
LOG RECORDING
MANAGE SD CARD
INFORMATION
Tab. 12: Card
Go to START PROGRAM
SET BOOT PROG.
DELETE PROGR.
CARD -> DEVICE
DEVICE -> CARD
Tab. 13: Card\Program
Select the starting program from the list containing the names of all the pro-
grams stored on the memory card.
The ✓ checkmark at the end of a line indicates the program with which the
easyE4 device will start as soon as RUN mode is active.
Name Program 1 ✓
Name Program 2
Name Program 3
...
Tab. 14: Card\Program\Start pro-
gram
If the display is empty, this means that no programs have
been stored on the memory card.
