4. Operation
4.1 Base device with display and buttons
4.1.3 Selecting menus and entering values
2x ALT
Calling the System menu
ESC
Return to the previous menu level
Cancel entries since last OK
OK
Move to the next menu level
Call menu item
Activate, change, save entries
Cursor but-
tons
Change menu item,
Change the value,
Activate, change, save entries
How the P button functions are mapped to the cursor buttons:
Input P1
Input P2
Input P3
Input P4
Press the OK button on the EASY-E4-... in order to open the menu from the
status display.
Use the cursor buttons to scroll through the individual menu options.
To confirm a selection, press OK. to open the corresponding menu path.
If necessary, use the cursor buttons while in a line to toggle between the
right and left display areas.
If this option is available, the ó character will appear.
easyE402/24 MN050009ENEaton.com
155
