2. Installation
2.3 Mounting
2.3 Mounting
ATTENTION
Arrange for a professional technician to mount the device.
CAUTION
INSTALLATION CUT-OUT
The mounting cutout must be located in a position that will not defeat
the purpose of stabilizing webs or other reinforcing elements in the
control panel. If necessary, reinforcing elements must be installed/ad-
ded.
Check to make sure that the installation clearances are being observed
→ Section " Installation position", page 54
Make sure that the mounting cutout has the right size.
Mounting EASY-E4-...
Mounting on ICE/EN 60715 mounting rail OR
with screws and ZB4-101-GF1 mounting feet.
2.3.1 Mounting easyE4 control relays
Install the easyE4 control relay in a control panel, service distribution board, or
enclosure so that the power supply and terminal connections cannot be touched dir-
ectly during operation.
The easyE4 control relay can be mounted either vertically or horizontally.
For ease of wiring, leave a clearance of at least 3 cm between the device terminals
and the wall or adjacent devices.
58
easyE402/24 MN050009ENEaton.com
