5. Programming on the device
5.5 Transferring programs from and to a microSD memory card
5.5.1 Configuration on a base device with a display
The program needs to be transferred using the Card menu option.
In order to be able to configure this option, the program must be in STOP mode. If it is
not, the device will point this out.
Go to the main menu.
Open the CARD menu option.
STOP ✓ RUN
PARAMETERS
SET CLOCK
CARD
INFORMATION
SYSTEM OPTIONS
PROGRAM
Tab. 77: Main menu
The device menu for the memory card will appear with additional menu options.
PROGRAM
LOG RECORDING
MANAGE SD CARD
INFORMATION
Tab. 78: Card
PROGRAM Used to manage the programs on the device
LOGS Data can be written to a binary file by using the DL (Data Logger)
manufacturer function block. These logs can be managed here.
MANAGE CARD Used to format and eject the card
INFORMATION Provides information on the card size and the amount of free
space left
214
easyE402/24 MN050009ENEaton.com
