4. Operation
4.3 Operation of the menu selection and value entry
4.3.3 Selecting a device menu
You can use the main menu from the status display in order to access the individual
submenus.
Press the OK button.
The main menu will appear.
The scrollbar on the right side will indicate whether there are additional menu
options.
Please note that since the display has six lines only, you may need to use the
cursor buttons to scroll to the remaining available lines on a screen
STOP ✓ RUN
PARAMETERS
SET CLOCK
CARD
INFORMATION
SYSTEM OPTIONS
PROGRAM
Tab. 24: Main menu
A horizontal scroll bar indicates that other selection options are available. You may
be able to reach them using the cursor keys .
160
easyE402/24 MN050009ENEaton.com
