Eaton easyE4 User Manual

4. Operation
4.4 Overview of the menus on the device
4.4.3 Parameter menu
This submenu lists the function blocks that are being used in the current program.
This makes it possible to change the values of constants in the program at runtime
without having to stop or re-transfer the program.
When the password is activated and the +/- basic parameter for each function block
is set, you can allow or deny the operator of the system the possibility to change the
values.
Function blocks with basic parameters that you have set to + via the +/- character in
the function block editor are displayed in the PARAMETERS menu and can be
changed. It is only possible to change constants. Other operands cannot be changed.
It is also possible to change parameters via the PARAMETERS menu if you have
saved the program and therefore password protected the function block editor.
To immediately apply a change to the individual constants, press the OK button.
Press the ESC button to cancel the change instead.
 List of function blocks in
the current program,
e.g.,
The current program
does not use any func-
tion blocks
STOP ✓ RUN
PARAMETERS
SET CLOCK
CARD
INFORMATION
SYSTEM OPTIONS
PROGRAM
Tab. 29: Parameter
T 01 Ü S +
C 02
L:1 STOP
Tab. 30: Parameter
NO FUNCTION BLOCKS
INCLUDED!
Tab. 31: Parameter
Pressing the OK button will show the parameters for the individual function blocks in
an additional submenu that can be used to modify these parameters with the cursor
buttons.

T 01 Ü S +
>I1 000 800
>I2 009 200
QV> 000 000
..
Tab. 32: Timer module
example

162
easyE402/24 MN050009ENEaton.com
