1. Description of easyE4 control relay
1.5 Accessory devices
1.5 Accessory devices
In addition to the expansions, there are additional accessories available for easyE4
control relays.
NOTICE
Only use original accessories.
Order accessories through your supplier or through the EATON
online catalog
Example:
Cat No. and type Description
198513 XV-102-AO-35TQRB-1E4
Touch display for easyE4, 3.5 inches,
24 V
DC
, TFTcolor, QVGA 320 x 240 pixels, Ethernet
199734 XV-102-A3-57TVRB-1E4
Touch display for easyE4, 5.7 inches,
24 V
DC
, TFTcolor, VGA 640 x 480 pixels, Ethernet
199740 EASY-RTD-DC-43-03B1-00
easy Remote Touch Display, easyE RTD Standard, 4.3 inches,
24 V
DC
, TFTcolor, 480x272 px, Res., Ethernet, RS485
EP-401057 EASY-RTD-DC-43-03B2-
00
easy Remote Touch Display, easyE RTD Advanced, 4.3 inches,
24 V
DC
, TFTcolor, 480x272 px, Res., Ethernet, RS485
191087 MEMORY-SUD-A1
microSD
2 GB memory card with adapter, I Grade, without an operating system
197226 EASYSOFT-SWLIC
programming softwarelicense easySoft 8
061360 ZB4-101-GF1
EASY Fixing bracket, Device foot for screw mounting
197225 EASY-E4-CONNECT1
Spare parts package consists of three (3) connectors and three (3) end
covers for the easyE4 series between the control relay and input/out-
put expansions
199513 EASY-E4-CONNECT-COM1
Spare parts package consists of three (3) connectors and three (3) end
covers for the easyE4 series between the control relay and com-
munication module
229424 EASY200-POW
Switched-mode power supply unit,
100-240 V
AC
/ 24 V
DC
/ 12 V
DC
, 0.35 A / 0.02 A, single-phase, con-
trolled
212319 EASY400-POW
Switched-mode power supply unit,
100-240 V
AC
/ 24 V
DC
, 1.25 A, single-phase, controlled
272484 TR-G2/24
Transformer, 230 V, 12/24V, 2/1 A
easyE402/24 MN050009ENEaton.com
33
