DS-1100KI Network Keyboard User Manual
12
Chapter 2 Operation Guide
2.1 User Account
The keyboard user account is classified to two types: the admin and the operator.
The admin user is authorized with the following operation permissions:
1. Add a maximum of 3 operators;
2. Configure the keyboard parameters;
3. Add, edit and delete device;
4. Add, edit and delete user, as well as assign device for the user;
5. Assign segments for B20 MVC/multi-screen controller/decoder supporting roaming window.
The operator user is allowed to operate the assigned device only;
Up to 1280 devices can be assigned for each operator.
Figure 2. 1 Admin Permissions
2.2 Indicators and Buttons
Figure 2. 2 Indicators
Table 2. 1 LED Indicators on Panel
