DS-1100KI Network Keyboard User Manual
131
Chapter 8 Keyboard Configuration Tool
Purpose:
The configuration tool of the DS-1100KI keyboard is used to facilitate the parameters configuration of the
keyboard.
8.1 System Requirements
System requirement: 32-bit Windows XP / Windows 7.
Running conditions: please place the application program in the same directory where the HCNetSDK.dll, hpr.dll,
and Sadp.dll files locate. If the SADP software is not useable, please install the WinPcap_4_1_2.exe first.
8.2 Features
The following functions can be realized by operating the keyboard configuration tool:
 Add/Edit/Delete the user account.
 Add/Edit/Delete the device under the Administrator.
 Add/Delete the device under the Operator.
 Link the device to stream media server in single/batch mode.
 Delete the channel under the Operator.
 Save channel information of the user to local directory in text document.
 Import/Export the configuration file.
 Export the input/output list as the .txt file.
 Upgrade the keyboard.
8.3 Selecting Login Mode to Configuration Tool
Run the application program to enter the following interface:
Figure 8. 1 Login Interface
Select the mode for configuration. Three modes are selectable: Local Config File, Remote Config File and Update

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
