DS-1100KI Network Keyboard User Manual
65
4. Select the outputs from the list to be added to the group, and then click Add to finish the setting.
5. Click Finish to return to the Output Group interface, where you can view the successfully added output
channels for the current group.
You can click to delete the added output.
4.4.4 Setting Video Wall/Scene
Steps:
1. Click the Wall/Scene button to enter the Video Wall/Scene List.
Video wall list: It mainly aims at DS-6400HD-T decoder.
Scene list: It aims at B20/multi-screen controller/64-S decoder. The scenes in the list are the ones configured
well via client software.
Figure 4. 54 Setting Video Wall/Scene
4.5 Macro Settings
The macro command can be used for operating a series of continuous actions in sequence.
Operation: Press the “Num + MAC” keys to call the programmed macro command.
Click Macro on the main interface to enter the Macro Settings interface.
Figure 4. 55 Macro Settings
Adding Macro
Click Add Macro to enter the Macro Setting-Add Macro interface. Edit the macro name, and press the command

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
