U-flash disk.
When the current window is configured with multiple channels for display (in cycle view mode), the
error message will appear on the screen as well.
5.5.3 Recording
The video from the camera can be recorded and saved in the local U-flash disk or uploaded to FTP server as well.
Operation method 1:
1. Press the Num + MON keys to select the output channel.
2. Press the Num + WIN keys to select the display window.
3. Press the REC key to start video recording.
Operation method 2:
1. Press the Num + CAM keys to select the input channel.
2. Press the REC key to start video recording.
During the recording, the REC key on the keyboard lights in red. When you exit the operation interface,
the recording continues and you are allowed to stop it. When the window is configured with multiple channels for
display (in cycle view mode), the error message will appear on the screen. And if the current window or output
channel is performing playback by time, then the recording operation is not allowed.
5.5.4 Other Functions
The PREV and NEXT keys on the keyboard are used to select the previous or next camera during the shortcut
operation.
Operation method 1:
1. Press the Num + MON keys to select the output channel.
2. Press the Num + WIN keys to select the display window.
3. Press the PREV/NEXT key to select the previous or next camera.
If the current window is not in the dynamic decoding mode, it is invalid to press the PREV/NEXT key.
When the window is configured with multiple channels for display (in cycle view mode), the error message will
appear on the screen.
Operation method 2:
1. Press the Num + CAM keys to select the input channel.
2. Press the PREV/NEXT key to select the previous or next camera.
