DS-1100KI Network Keyboard User Manual
67
Figure 4. 58 Macro List
Deleting Macro
You can click to delete the added macro command.
4.6 Playback
The video files stored in the encoding device can be played back through the related decoder. Three playback
modes are available: playback by USB file, playback by time and playback by file.
Click Playback on the main interface to enter the Local Playback interface.
Figure 4. 59 Local Playback
4.6.1 Playback by USB File
Steps:
1. Connect your USB disk to the keyboard.
2. Click the USB File tab on the Local Playback interface to enter the Playback by Local File interface.

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
