DS-1100KI Network Keyboard User Manual
27
Figure 3. 7 Network Settings
3.3.3 Configuring Hardware Settings
Sound Effect/Alarm Sound/Key Light: Click the corresponding checkbox to to enable the function, or remain
it as to disable the function.
The key light defaults to be on. Alarm will be sounded when the network is disconnected or the IP is
conflicting.
Keyboard Lock Delay, Screen Off Delay: Use the or to decrease or increase the key lock timeout and the
screen-close timeout, with the range of 0~10 minute (s) configurable. When the value is set to 0, the key and
screen will be unlocked.
The LOCK indicator will be on after keyboard lock. Re-login should be done after unlocking.
Background Contrast: Click to select the value from the drop-down menu, with the 3: 1, 1: 1, 1: 3 and
non-transparent optional.
The Background Contrast refers to the contrast of the local decoded video and menu, and is valid only
for the local live view.
Mouse Speed: Select the mouse speed to level 0~3.
Screen Brightness: Select the screen brightness to level 0~4.
Click Apply to save the settings.
Figure 3. 8 Hardware Settings

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
