DS-1100KI Network Keyboard User Manual
79
4. Repeat Step 3 to set other cameras.
5. Press the SET key to finish the tour settings.
The tour settings will not be saved after the keyboard is rebooted.
Figure 5. 9 Setting a Tour
Up to 8 tours can be supported currently.
The dwell time of the tour is the length of time used for switching from one camera to the next camera in the tour.
All cameras are set with the same dwell time.
 When the device is restarted, all the tour settings will be invalid.
 All programmed parameters will be cleared if you press the Num + TOUR keys again in the process of setting
tour.
 Corresponding error message will appear on the screen when you perform wrong operation.
5.3.7 Calling a Tour
Steps:
1. Press the Num + MON keys to select the monitor for display.
2. Press the Num + TOUR keys to call the programmed tour to be displayed on the selected monitor.
Figure 5. 10 Calling a Tour

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
