HIKVISION DS-1100KI User Manual

DS-1100KI Network Keyboard User Manual
26
If the password you set is weak, the message box “Weak password” will pop out, but you are able to finish the
password settings.
Figure 3. 5 Message Boxes
2. Click OK to finish the password changing.
3.3 Keyboard Management
On the main interface of admin, click the Keyboard on the left navigation bar to enter the Keyboard Management
interface. In the Keyboard Management interface, you can view the device version information, configure network
parameters, configure hardware settings, adjust time, select language, screen calibration and upgrade system.
3.3.1 Viewing Version Information
Click Version to enter the Keyboard-Version interface to view the current version information of the keyboard.
Figure 3. 6 Version Information
3.3.2 Configuring Network Settings
Configure the network settings of the keyboard, including the Port, IP address, Subnet Mask, Default Gateway,
Preferred DNS and Alternate DNS. Click Apply to save the settings.
Make sure the DHCP is supported by the router before enabling the function.

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
