DS-1100KI Network Keyboard User Manual
85
Figure 5. 18 Calling a Preset
Corresponding error message will appear on the screen when you perform wrong operation.
• Calling a Preset by Input Channel
Steps:
1. Press the Num + CAM keys to select the input channel.
2. Press the Num + CALL keys to call the programmed preset.
It is invalid to input the 0+CAM keys in the current operation mode.
Figure 5. 19 Calling a Preset by Input Channel
Corresponding error message will appear on the screen when you perform wrong operation.
5.4.4 Setting a Patrol
Select the output monitor or window and the keyboard is capable of automatically connecting with its
corresponding camera. Press the SET key on the keyboard and then press PATROL key to enter the patrol settings
interface. You are also allowed to directly select the camera by inputting Num + CAM keys and then press the SET
key to start patrol settings.
• Setting a Patrol by Output Channel
Steps:
1. Press the Num + MON keys to select the output channel.

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
