DS-1100KI Network Keyboard User Manual
55
Figure 4. 32 Stream Media Settins
2. Enable the Stream Media by checking the checkbox.
3. Input the IP address and port of the server.
The Server IP refers to the IP address of the PC on which the stream media software is running.
4. You can check the checkbox of Copy to all to copy the current stream media settings to all encoding devices
under the current login user. If you uncheck it, the stream media settings are applicable to the current
encoding device only.
5. Click Apply to save the settings.
4.2 Decoder Settings
Click the of a decoder on the Device List interface and enter its remote settings.
On this interface, you can configure the settings for network, RS-232/RS-485 serial port, output, decoding status,
maintenance, etc.
Figure 4. 33 Decoder Settings
4.2.1 Network Settings
Click Network on the remote settings interface to enter the Network Settings interface.
You can configure the general settings, advanced settings, PPPoE, DDNS and NTP parameters of the decoder.

HIKVISION DS-1100KI Specifications

General

Split keyboard	No
Keyboard layout	-
Device interface	RS-232 + RS-485 + RJ-45
Recommended usage	Office
Keyboard form factor	Mini
Connectivity technology	Wired
Display type	TFT
Product color	Black
Keyboard style	Straight
Ergonomic design	Yes
Product type	Control panel
Housing material	Plastic
Quantity per pack	1 pc(s)
USB 2.0 ports quantity	1
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Operating voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	110 mm
Width	435 mm
Height	193 mm
Keyboard weight	2000 g
Keyboard dimensions (WxDxH)	435 x 110 x 193 mm
