Hitachi ZAXIS 135US-6 class User Manual

OPERATOR'S STATION
1-112
1
21
11
31
4
24
14
34
7
27
17
37
2
22
12
32
5
25
15
35
8
28
18
38
3
23
13
33
6
26
16
36
9
29
19
39
10
30
20
40
A
B
Fuse Box
A
10- CONTROLLER
5 A
20- OPT.3 (ALT)
5 A
9- BACKUP
10 A
19- HORN
10 A
8- ECU
30 A
18- IDLE STOP
5 A
7- START
5 A
17- POWER ON
5 A
6- OPT.2 (ALT)
20 A
16- GLOW RELAY
5 A
5- OPT.1 (ALT)
5 A
15- AUX
10 A
4- SOLENOID
20 A
14- MONITOR
5 A
3- HEATER
20 A
13- LIGHTER
10 A
2- WIPER
10 A
12- RADIO
5 A
1- LAMP
20 A
11- FUEL PUMP
5 A
B
30- - 40- -
29- - 39- -
28- SENSOR_UNIT
10 A
38- -
27- AUX.3
5 A
37- -
26- QUICK HITCH
5 A
36- -
25- IMMOBI
5 A
35- DCU
20 A
24- 12VUNIT
10 A
34- AUX.2
10 A
23- CAB LAMP REAR
10 A
33- WARNING LAMP
10 A
22- CAB LAMP FRONT
10 A
32- CAB LAMP FRONT +2
10 A
21- SEAT HEATER
10 A
31- SEAT COMPR.
10 A
M1GR-01-003
M1GR-01-003
A
B
MDCN-01-010
