MAINTENANCE
7-69
12. Remove drain plug (3). Allow oil to drain.
13. Clean, install and tighten drain plug (3).
14. Add oil until it is between the marks on the oil level
gauge.
15. Install cover (2). Tighten the bolts to 50 N·m (5.0 kgf·m).
16. Be sure to bleed air from the system following the
procedures shown on the next page.
Sampling the Engine Oil
f
NOTE: The line is equipped with a valve (10) for sampling
the engine oil. The valve has a cap (9). For instructions on
sampling the engine oil, consult your authorized dealer.
M1U1-07-047
3
M157-07-062
2
4
5
MDAT-07-087
To Next Page
