SPECIFICATIONS
12-11
Shoe Types and Applications
ZX345USLC-6
Shoe Width
600 mm
Grouser Shoe
700 mm
Grouser Shoe
800 mm
Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg 36300 36900 37300
Base Machine Weight kg 21200 21800 22200
Cab Height mm 3230 3230 3230
Minimum Ground Clearance mm * 500 * 500 * 500
Undercarriage Length mm 4940 4940 4940
Undercarriage Width mm 3190 3290 3390
Ground Pressure
68 kPa
(0.69 kgf/cm
2
)
59 kPa
(0.60 kgf/cm
2
)
52 kPa
(0.53 kgf/cm
2
)
f
NOTE:
The Specifications for the front-end attachment is for 3.11 m arm with PCSA 1.25 m
3
bucket.
700, 800 mm grouser shoe should not be used on gravel or rocky ground.
* The dimensions do not include the height of the shoe lug.
