SPECIFICATIONS
12-4
Bucket Types and Applications
ZX135US-6
Bucket
Bucket Capacity
m
3
Bucket Width
mm
Front-End
Attachment
PCSA
(Heaped)
CECE
(Heaped)
With Side
Cutters
Without
Side
Cutters
3.01 m
Arm
Hoe Bucket
0.19 0.17 550 450
0.30 0.25 700 580
0.40 0.33 800 680
0.45 0.40 970 850
0.50 0.45 1010 890 *
0.59 0.50 1070 950 -
0.66 0.55 - 1030 -
Reinforced Hoe Bucket 0.50 0.45 1010 890 *
Reinforced Hoe Bucket 0.59 0.50 1070 950 -
One Point Ripper - - - -
Slope-Finishing Blade - 1000 x 1600
V-Type Bucket -
f
NOTE:
Symbols in the above table have the following meanings.
: General excavating
: Light duty excavating
: Rock digging
: Loading work
: Slope-finishing work
- : Not applicable (not warrantable)
Hoe bucket is applicable to the following types of work.
General excavating:
For digging and loading operation of sand, gravel, clay, ordinary earth and so on.
Light duty excavating:
For digging and loading operation of dry, loosened earth, sand, mud and so on.
Their bulk density shall be less than 1.60 t/m
3
as a standard.
Loading:
For loading operation of dry, loosened earth and sand.
Their bulk density shall be less than 1.10 t/m
3
as a standard.
Rock digging:
For digging/loading operation of mountain gravels, blasted rock, hard clay, soft rock and so on.
* Applicable only to 700 mm grouser shoe.
IMPORTANT: Using inapplicable buckets may cause serious damage to the front structure such as boom, arm and
hydraulic cylinders.
45 ˚
