13-11
OPTIONAL ATTACHMENTS AND DEVICES
BLADE
Blade Maintenance
Greasing --- every 250 hours
Lubricate all fittings shown in the figure.

Blade Joint Pins (2 points)
 Blade Cylinder Rod (2 points)
 Blade Cylinder Bottom (2 points)
Transportation Figure for Machine Equipped with Blade
When transporting the machine equipped with a blade
and a long arm front attachment on a trailer, place the
blade in the opposite position toward the front attachment.
Otherwise, the bucket may come in contact with the blade.
M175-13-002
M175-13-005
