6-1
TRANSPORTING
Transporting by Road
When transporting the machine on public roads, be sure to
first understand and follow all local regulations.
When transporting the machine using a trailer, check
the width, height, length and weight of the trailer with
the machine loaded. Note that transporting weight and
dimensions may vary depending on the type of shoe or
front attachments installed.
Investigate conditions on the route to be traveled in
advance, such as dimensional limits, weight limits, and
traffic regulations.
In some cases it may be necessary to obtain permission from
the local authority concerned, or to disassemble the machine
to bring it within local regulation for dimensional or weight
limits.
Notify your authorized dealer that you are transporting the
disassembled machine.
IMPORTANT: Remove the auxiliary bar when
transporting the machine. After transporting the
machine, install the auxiliary bar in the operation
position before operating the machine.
M1V1-06-001
Transportation Position
Operation Position
ZX225USLC-6
ZX225USLC-6
ZX135US-6, ZX225USLC-6
ZX135US-6
Transportation Position
ZX135US-6
Operation Position
MDAT-06-003
MDAT-06-004
MDAT-06-005
MDAT-06-006
MDAT-06-007
To Next Page
