SPECIFICATIONS
12-7
Shoe Types and Applications
ZX225USLC-6
Shoe Width
600 mm
Grouser Shoe
700 mm
Grouser Shoe
800 mm
Grouser Shoe
Application
For Ordinary Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg 25000 25400 25700
Base Machine
Weight
kg 20500 21000 21200
Counterweight
Weight
kg 7280 7280 7280
Cab Height mm 2950 2950 2950
Minimum Ground
Clearance
mm *450 *450 *450
Undercarriage
Length
mm 4460 4460 4460
Undercarriage
Width
mm 2990 3090 3190
Ground Pressure
52 kPa
(0.53 kgf/cm
2
)
45 kPa
(0.46 kgf/cm
2
)
40 kPa
(0.41 kgf/cm
2
)
f
NOTE:
The specifications for the front-end attachment is for 2.91 m arm with PCSA 0.8 m
3
bucket.
Other than 600 mm grouser shoe should not be used on gravel or rocky ground.
* The dimensions do not include the height of the shoe lug.
