MAINTENANCE

7-30

A. Greasing

Front Joint Pins

--- every 500 hours (first time after 250 hours)

Lubricate all fittings shown in the figure.



Boom Cylinder Bottom Side

 Boom Foot

M178-07-007

M157-07-156

MDAT-07-010

M178-07-082

ZX135US-6

ZX225USLC-6

MDD5-07-004

ZX345USLC-6
