Hitachi ZAXIS 135US-6 class User Manual

OPERATOR'S STATION
1-150
Mirror Installation Diagram
The mirror installation locations (1, 2, 3, 4, 5, 6) on this machine
are shown in the right.
Adjust the installation locations of each mirror by following
the instructions below to ensure safety.
Installation angle and dimension varies depending on the
model.
1- Operator's Seat Mirror
2- Handrail Mirror for Getting ON/OFF the Machine
3- Handrail Mirror for Getting ON/OFF the Machine
4- Oil Tank Handrail Mirror
5- Oil Tank Handrail Mirror (ZX135US-6 only)
6- Counterweight Mirror (ZX225USLC-6 only)
7- Fuel Tank Handrail Mirror (ZX345USLC-6 only)
8- Aftertreatment Device Cover Mirror (ZX345USLC-6 only)
The following models are not equipped with oil tank
handrail mirrors (4) (5) or counterweight mirror (6).
2
3
6
1
4
2
3
1
4
5
ZX135US-6
ZX225USLC-6
ZX345USLC-6
1
2
7
8
MDAT-01-225
MDAT-01-226
MDD5-01-012
