OPTIONAL ATTACHMENTS AND DEVICES
HYDRAULIC BREAKER, HYDRAULIC CRUSHER AND QUICK COUPLER
Attachment
Allowable Weight Limits of Installed Attachment
d
WARNING:
Before installing attachments such as hydraulic
breaker, crusher (concrete crusher), or pulverizer,
take machine controllability into account when
selecting the weight of the attachment by referring
to the table below.
When an attachment other than the standard bucket
is installed on the machine, the machine stability will
be different.
If a heavy attachment is used, not only will
controllability be affected but also machine stability
will be reduced, possibly causing safety hazard.
Unit: kg
Specification
Base Machine Breaker Crusher/Pulverizer
Model Arm Std.Weight Max.Weight Std.Weight Max.Weight
Std. Model
ZX135US-6 Std. 1000 1100 1200 1400
ZX225USLC-6 Std. 1750 1950 2100 2450
ZX345USLC-6 Std. 2400 2650 2900 3400
According to the specifications of installed
attachment and the base machine, the
machine weight may exceed the allowable
maximum operating weight of the ROPS,
making the ROPS unable to assure the
protective function for operator. Refer to the
ROPS certification for the allowable maximum
operating weight.
