Hitachi ZAXIS 135US-6 class User Manual

13-14
OPTIONAL ATTACHMENTS AND DEVICES
BLADE
Shoe Types and Applications
ZX135US-6 with Blade
Shoe Width
500 mm
Grouser Shoe
600 mm
Grouser Shoe
700 mm
Grouser Shoe
Application
For Ordinary
Ground
(Standard)
For Weak Footing
(Option)
For Weak Footing
(Option)
Operating Weight kg 15100 15700 16100
Base Machine Weight kg 11500 12100 12500
Counterweight Weight kg 3520 3520 3520
Cab Height mm 2790 2790 2790
Minimum Ground
Clearance
mm *410 *410 *410
Undercarriage Length mm 3580 3580 3580
Undercarriage Width mm 2490 2590 2690
Ground Pressure
47 kPa
(0.48 kgf/cm
2
)
41 kPa
(0.42 kgf/cm
2
)
36 kPa
(0.37 kgf/cm
2
)
f
NOTE:
The Specifications for the front-end attachment is for 2.52 m arm with PCSA 0.50 m3 bucket.
Other than 500 mm grouser shoe should not be used on gravel or rocky ground.
* The dimensions do not include the height of the shoe lug.
