Huawei Quidway S3100 Series User Manual

Operation Manual – Link Aggregation
Quidway S3100 Series Ethernet Switches Chapter 1
Link Aggregation Configuration
Huawei Technologies Proprietary
1-5
II. Network diagram
Figure 1-1 Network diagram for link aggregation configuration
III. Configuration procedure
 Note:
The following only lists the configuration for Switch A; configure Switch B in the similar
way.
# Create manual aggregation group 1.
[Quidway] link-aggregation group 1 mode manual
# Add the Ethernet ports Ethernet1/0/1 through Ethernet1/0/3 to aggregation group 1.
[Quidway] interface ethernet1/0/1
[Quidway-Ethernet1/0/1] port link-aggregation group 1
[Quidway-Ethernet1/0/1] interface ethernet1/0/2
[Quidway-Ethernet1/0/2] port link-aggregation group 1
[Quidway-Ethernet1/0/2] interface ethernet1/0/3
[Quidway-Ethernet1/0/3] port link-aggregation group 1
