Huawei Quidway S3100 Series User Manual

Operation Manual – FTP and TFTP
Quidway S3100 Series Ethernet Switches Chapter 1
FTP and TFTP Configuration
Huawei Technologies Proprietary
1-11
Device Configuration Default Description
PC
The TFTP server is started
and the TFTP work directory
is configured.
— —
1.2.2 TFTP Configuration
I. Prerequisites
A switch operates as a TFTP client. A PC operates as the TFTP server. The network
operates properly, as shown in
Figure 1-4.
II. Configuration procedure
Table 1-7 Configure TFTP
Operation Command Description
Set the TFTP file
transmission mode
tftp { ascii | binary }
Optional
By default, the binary file
transmission mode is
adopted.
Download a file
tftp tftp-server get
source-file [ dest-file ]
Optional
Upload a file
tftp tftp-server put
source-file [ dest-file ]
Optional
Enter system view
system-view
—
Specify the ACL
adopted when a
switch attempts to
connect a TFTP
server
tftp-server acl acl-number
Optional
1.2.3 Configuration Example
I. Network requirements
A switch and a PC operate as a TFTP client and the TFTP server.
z The TFTP work directory is configured on the TFTP server.
z The IP address of a VLAN interface on the switch is 1.1.1.1. The port through
which the switch connects with the PC belongs to the VLAN. The IP address of the
PC is 1.1.1.2.
