Huawei Quidway S3100 Series User Manual

Operation Manual – 802.1x
Quidway S3100 Series Ethernet Switches Chapter 1
802.1x Configuration
Huawei Technologies Proprietary
1-15
Operation Command Description
Create a RADIUS
scheme and enter
RADIUS scheme
view
radius scheme
radius-scheme-name
Optional
The default RADIUS scheme
is “system”. This command is
required if the name of the
RADIUS scheme adopted in
the ISP domain is not
“system”.
Set the IP address
and port number
used by the
primary RADIUS
authentication/auth
orization server
primary authentication
ip-address [ port-number ]
Optional
This command is required if
the name of the RADIUS
scheme adopted in the ISP
domain is not “system”.
Caution:
z 802.1x-related configurations can all be performed in system view. Port access
control mode and port access method can also be configured in port view.
z If you perform a configuration in system view and do not specify the interface-list
argument, the configuration applies to all ports. Configurations performed in
Ethernet port view apply to the current Ethernet port only and the interface-list
argument is not needed in this case.
z 802.1x configurations take effect only after you enable 802.1x both globally and for
specified ports.
1.4 Timer and Maximum User Number Configuration
Table 1-2 Configure 802.1x timers and the maximum number of users
Operation Command Description
Enter system view
system-view
—
In system view:
dot1
inter
x max-user
user-number [ interface
face-list ]
Configure the
maximum number
of concurrent
on-line users for
specified ports
In port view:
dot1x max-user
user-number
Optional
By default, up to 256
concurrent on-line users are
allowed on each port.
