Operation Manual – QoS
Quidway S3100 Series Ethernet Switches Chapter 1
QoS Configuration
Huawei Technologies Proprietary
1-8
IP precedence Local precedence queue
6 3
7 3
1.5.4 Configuring “DSCP Precedence - Local Precedence Queue” Mapping
Table
Table 1-8 Configure the “DSCP precedence - local precedence queue” mapping table
Operation Command Description
Enter system view
system-view
—
Configure the
mapping table
qos
dscp-local-precedence-map
dscp-list : local-precedence
Required
Display the
mapping table
display qos
dscp-local-precedence-map
Can be executed in any
view.
The following table shows the default “DSCP precedence - local precedence queue”
mapping table.
Table 1-9 Default “DSCP precedence - local precedence queue” mapping table
DSCP precedence Local precedence queue
0–15 0
16–31 1
32–47 2
48–63 3
1.5.5 Configuration Example
I. Network requirements
Modify the “802.1p priority - local precedence queue” mapping table as follows.
Table 1-10 “802.1p priority - local precedence queue” mapping table
802.1p priority Local precedence queue
0 0
1 0
2 1
