Huawei Quidway S3100 Series User Manual

Operation Manual – MSTP
Quidway S3100 Series Ethernet Switches Chapter 1
MSTP Configuration
Huawei Technologies Proprietary
1-26
1.3.4 Timeout Time Factor Configuration
Refer to section 1.2.9 “Timeout Time Factor Configuration”.
1.3.5 Maximum Transmitting Speed Configuration
Refer to section 1.2.10 “Maximum Transmitting Speed Configuration”.
1.3.6 Edge Port Configuration
Refer to section 1.2.11 “Edge Port Configuration”.
1.3.7 Path Cost Configuration
The path cost parameters reflects the link rates on ports. For a port on an
MSTP-enabled switch, the path cost may differ with spanning tree instance. You can
enable flows of different VLANs to travel along different physical links by configuring
appropriate path costs on ports, so that load balancing can be achieved by VLANs.
The switch can automatically calculate the path costs of ports, but you can also
manually configure them.
I. Standards for calculating path costs of ports
Currently, a switch can calculate the path costs of ports based on one of the following
standards:
z dot1d-1998: Adopts the IEEE 802.1D-1998 standard to calculate the default path
costs of ports.
z dot1t: Adopts the IEEE 802.1t standard to calculate the default path costs of ports.
z legacy: Adopts the standard defined by Huawei-3Com to calculate the default
path costs of ports.
Table 1-21 Specify the standard for calculating path costs
Operation Command Description
Enter system view
system-view
—
Specify the
standard to be
used to calculate
the default path
costs of the links
connected to the
switch
stp pathcost-standard
{ dot1d-1998 | dot1t |
legacy }
Optional
By default, the IEEE 802.1t
standard is used to calculate
the default path costs of ports.
