Juniper EX9214 Hardware Guide

• You can congure a port to operate at 40-Gbps speed and install a 40-gigabit QSFP+ transceiver
in the port.
• You can congure the ports labeled 0/2, 0/5, 1/2, and 1/5 (see Figure 33 on page 95) to operate
at 100-Gbps speed and install 100-gigabit QSFP+ transceivers in these ports.
• Twelve dust covers for the ports
• Line card LED—An LED labeled OK/FAIL, which indicates the status of the line card. See Line Card
LED in an EX9200 Switch .
• Network port LED—Four LEDs for each network port, the Link/Acvity LED, which indicates the link
status and acvity on the port. See Network Port LEDs on Line Cards in an EX9200 Switch .
There are four LEDs labeled 0, 1, 2, and 3 for each port (see Figure 33 on page 95). If a port is
congured to operate at 10-Gbps speed, four 10-Gbps interfaces are created and the LEDs labeled 0,
1, 2, and 3 for that port becomes operaonal. Each of these LEDs indicates the link/acvity on each
interface on the corresponding port. If a port is congured to operate at 40-Gbps speed, the LED
labeled 0 for that port becomes operaonal. If the ports labeled 0/2, 0/5, 1/2, and 1/5 are
congured to operate at 100-Gbps speed, the LED labeled 3 for each of these ports becomes
operaonal.
You can nd the list of transceivers supported on the EX9200-12QS line card at the Hardware
Compability Tool page for the EX9200-12QS line card.
The ports are divided into two port groups. The six ports labeled 0/0 through 0/5 form one port group,
PIC 0. The six ports labeled 1/0 through 1/5 form the other port group, PIC 1. The ports in each group
share 240 gigabits of bandwidth. Thus, you can transmit up to 240 gigabits of trac through a port
group without packet drop.
EX9200-15C Line Card
IN THIS SECTION
Line Card Models | 97
Line Card Components | 98
EX9200-15C Power Requirements | 99
EX9200-15C LEDs | 99
Cables and Connectors | 100
96
