Switch Fabric Module LEDs in an EX9200 Switch
The Switch Fabric module (SF module) has three LEDs on the module faceplate. Table 24 on page 71
describes the funcons of these LEDs. For informaon about the LEDs on the EX9200-SF3, see Table
24 on page 71.
Table 24: SF Module LEDs of an EX9200 Switch
LED Status Descripon
FABRIC ACTIVE Green Switch Fabric is in acve mode.
Unlit Switch Fabric is oine.
FABRIC ONLY Green On steadily—Switch Fabric is operang in fabric-only
mode.
Unlit Switch Fabric is not operang in fabric-only mode.
OK/FAIL Green Switch Fabric is online.
Red Switch Fabric has failed.
Unlit Switch Fabric is oine.
The BITS, GPS, and UTI LEDs, located next to the EXT CLK port, indicate the status of the respecve
clocking interface. These LEDs are not supported.
EX9200-SF3 Module in an EX9200 Switch
IN THIS SECTION
EX9200-SF3 Components and Features | 74
EX9200-SF3 LEDs | 75
