Table 19: DC Power Supply LEDs in EX9214 Switches (Connued)
Feed
Mode
Descripon LEDs
INP0 OK INP1 OK DC OK PS FAIL
Two-
Feed
The power input to the INP-0 DC
power inlet located on the power
supply is connected and the power
input to the INP-1 DC power inlet
located on the power supply is not
connected; the input is within the
acceptable range, but the power
supply is funconing normally and is
not providing power to the switch
chassis.
Green O O Red
The power input to the INP-1 DC
power inlet located on the power
supply is connected and the power
input to the INP-0 DC power inlet
located on the power supply is not
connected; the input is within the
acceptable range, but the power
supply is not funconing normally
and is not providing power to the
switch chassis.
O Green O Red
The power inputs to the INP-0 and
INP-1 DC power inlets located on
the power supply are connected; the
inputs are within the acceptable
ranges and the power supply is
funconing normally and providing
power to the switch chassis.
Green Green Green O
Power Requirements for EX9200 Switch Components
Table 20 on page 58 lists the power requirements for dierent hardware components of EX9200
switches.
