Maintain Fiber-Opc Cables
IN THIS SECTION
Connect a Fiber-Opc Cable | 274
Disconnect a Fiber-Opc Cable | 275
How to Handle Fiber-Opc Cables | 276
Connect a
Fiber-Opc Cable
Before you connect a ber-opc cable to an opcal transceiver installed in a device, ensure that you
have taken the necessary precauons for safe handling of lasers (see
Laser and LED Safety Guidelines
and Warnings
).
To connect a ber-opc cable to an opcal transceiver installed in a device:
LASER WARNING: Do not look directly into a ber-opc transceiver or into the ends of
ber-opc cables. Fiber-opc transceivers and ber-opc cables connected to
transceivers emit laser light that can damage your eyes.
1. If the ber-opc cable connector is covered with a rubber safety cap, remove the cap. Save the cap.
2. Remove the rubber safety cap from the opcal transceiver. Save the cap.
3. Insert the cable connector into the opcal transceiver (see Figure 90 on page 274).
Figure 90: Connect a Fiber-Opc Cable to an Opcal Transceiver Installed in a Device
g000704
Transceiver
Fiber-optic
cable
