Table 4: CLI Equivalents of Terms Used in Documentaon for EX9214 Switches
(Connued)
Hardware
Item (CLI)
Descripon (CLI) Value (CLI) Item in
Documentaon
Addional
Informaon
Fan Tray (
n
) Fan Tray
n
is a value in the range
0-1. The value
corresponds to the fan
tray slot number.
Fan tray "EX9214 Cooling
System" on page 40
Chassis Physical Specicaons of an EX9214 Switch
The EX9214 switch chassis is a rigid sheet-metal structure that houses the other switch components.
Table 5 on page 20 summarizes the physical specicaons of the EX9214 switch chassis.
See Figure 4 on page 23, Figure 5 on page 24, and Figure 6 on page 25.
Table 5: Physical
Specicaons of the EX9214 Switch Chassis
Descripon Weight Height Width Depth
Chassis Chassis with
midplane, two fan
trays, air lter, and
cable management
bracket: 150 lb
(68.04 kg)
Chassis with
maximum
conguraon: 350 lb
(158.8 kg)
27.8 in. (70.5 cm) 17.5 in. (44.5 cm)
(excluding the
mounng anges or
brackets)
Depth with AC
power supply:
31.08 in. (78.94 cm)
Depth with DC
power supply:
32.65 in. (82.93 cm)
Roung Engine
module (RE
module)
2.4 lb (1.09 kg) 1.25 in. (3.2 cm) 11 in. (27.9 cm) 7.75 in. (19.7 cm)
20
