Juniper EX9214 Hardware Guide

FPGA Revision 13
PMBus Expected Measured Measured Calculated
device voltage voltage current power
XF ASIC A 1000 mV 997 mV 13609 mA 13568 mW
XF ASIC B 1000 mV 1000 mV 12484 mA 12484 mW
The output is of an EX9208 switch. The output is similar for all EX9200 switches.
For more informaon about using the CLI, see the Junos OS documentaon.
Maintaining the EX9200 Line Cards
IN THIS SECTION
Handling and Storing Line Cards | 246
Maintaining Line Card Cables | 250
Unpacking a Line Card Used in an EX9200 Switch | 250
Removing a Line Card from an EX9200 Switch | 251
Installing a Line Card in an EX9200 Switch | 254
Removing a MIC from an EX9200-MPC Line Card | 256
Installing a MIC in an EX9200-MPC Line Card | 260
Handling and Storing Line Cards
IN THIS SECTION
Holding a Line Card | 247
Storing a Line Card | 249
246
