RJ-45 to DB-9 Serial Port Adapter Pinout Informaon
The console port on a Juniper Networks device is an RS-232 serial interface that uses an RJ-45
connector to connect to a management device such as a laptop or a desktop PC. If your laptop or
desktop PC does not have a DB-9 plug connector pin and you want to connect your laptop or desktop
PC to the device, use a combinaon of the RJ-45 to DB-9 socket adapter along with a USB to DB-9 plug
adapter.
Table 54 on page 146 provides the pinout informaon for the RJ-45 to DB-9 serial port adapter.
Table 54: RJ-45 to DB-9 Serial Port Adapter Pinout Informaon
RJ-45 pin Signal DB-9 pin Signal
1 RTS 8 CTS
2 DTR 6 DSR
3 TxD 2 RxD
4 GND 5 GND
6 RxD 3 TxD
7 DSR 4 DTR
8 CTS 7 RTS
