Lenze i55AE155F User Manual

Parameter Name / value range / [default seng] Info
0x4008:002
(P590.02)
Process input words: NetWordIN2
(NetWordINx: NetWordIN2)
0x0000 ... [0x0000] ... 0xFFFF
Mappable data word for oponal control of the digital outputs via net-
work.
Assignment of the digital outputs:
•
Relay: 0x2634:001 (P420.01) / selecon [34] ... [49]
•
Digital output 1: 0x2634:002 (P420.02) / selecon [34] ... [49]
•
Digital output 2: 0x2634:003 (P420.03) / selecon [34] ... [49]
Bit 0 Mapping bit 0
Bit 1 Mapping bit 1
Bit 2 Mapping bit 2
Bit 3 Mapping bit 3
Bit 4 Mapping bit 4
Bit 5 Mapping bit 5
Bit 6 Mapping bit 6
Bit 7 Mapping bit 7
Bit 8 Mapping bit 8
Bit 9 Mapping bit 9
Bit 10 Mapping bit 10
Bit 11 Mapping bit 11
Bit 12 Mapping bit 12
Bit 13 Mapping bit 13
Bit 14 Mapping bit 14
Bit 15 Mapping bit 15
0x4008:003
(P590.03)
Process input words: NetWordIN3
(NetWordINx: NetWordIN3)
0.0 ... [0.0] ... 100.0 %
Mappable data word for oponal control of an analog output via net-
work.
Assignment of the analog outputs:
•
Analog output 1: 0x2639:002 (P440.02) = "NetWordIN3 [20]"
•
Analog output 2: 0x263A:002 (P441.02) = "NetWordIN3 [20]"
0x4008:004
(P590.04)
Process input words: NetWordIN4
(NetWordINx: NetWordIN4)
0.0 ... [0.0] ... 100.0 %
Mappable data word for oponal control of an analog output via net-
work.
Assignment of the analog outputs:
•
Analog output 1: 0x2639:002 (P440.02) = "NetWordIN4 [21]"
•
Analog output 2: 0x263A:002 (P441.02) = "NetWordIN4 [21]"
0x4008:005
(P550.05)
Process input words: NetWordIN5
(NetWordINx: NetWordIN5)
-100.0 ... [0.0] ... 100.0 %
Mappable data word for oponally specifying an addive voltage set-
point via network.
•
100 % ≡ Rated voltage 0x2C01:007 (P320.07)
•
This value is used if "Network [3]" is selected in 0x2B13:002.
Conguring the network
Predened process data words
Further process data
253
