Lenze i55AE155F User Manual

4.2.7.2 Fusing and terminal data
Fuse data
Inverter I55AE230F
I55AE240F
I55AE255F
I55AE275F I55AE311F I55AE315F
Cable installaon in compliance with EN 60204-1
Installaon method B2
operaon without mains choke without mains choke
Fuse
Characteriscs gG/gL or gRL - gG/gL or gRL
Max. rated current A 25 32 - 63
Circuit breaker
Characteriscs B - B
Max. rated current A 25 32 - 63
operaon with mains choke
Fuse
Characteriscs gG/gL or gRL
Max. rated current A 25 32 32 63
Circuit breaker
Characteriscs B
Max. rated current A 25 32 32 63
Earth-leakage circuit breaker
3-phase mains connecon ≥ 300 mA, type B
Fuse data
Inverter I55AE318F
I55AE322F
I55AE330F I55AE337F I55AE345F
Cable installaon in compliance with EN 60204-1
Installaon method B2 C
operaon
Fuse
Characteriscs -
Max. rated current A - - - -
Circuit breaker
Characteriscs -
Max. rated current A - - - -
operaon with mains choke
Fuse
Characteriscs gG/gL or gRL
Max. rated current A 63 80 100 125
Circuit breaker
Characteriscs B
Max. rated current A 63 80 100 125
Earth-leakage circuit breaker
3-phase mains connecon ≥ 300 mA, type B
Electrical installaon
Mains connecon
3-phase mains connecon 480 V "Light Duty"
59
