Commissioning
For commissioning the sequencer, we recommend the following proceeding:
1.
Congure segments (including end segment).
Details: 4Segment conguraon ^ 506
2.
Congure sequences:
a)
Assign the segments to the single steps of a sequence.
b)
Set the number of cycles for the respecve sequence.
Details: 4Sequence
conguraon ^ 516
3.
Make the basic seng of the sequencer:
a)
Set the desired operang mode (me and/or step operaon).
b)
Oponally: Adapt end of sequence mode and start of sequence mode.
Details: 4Sequencer basic sengs ^ 520
4.
Congure the control of the sequencer:
a)
Assign the funcons for selecng a sequence to suitable triggers (e. g. digital inputs).
b)
Assign the funcons for controlling the sequencer (start, stop, cancel, ...) to suitable
triggers.
Details: 4Sequencer control
funcons ^ 588
Control
The funcons listed in the following table serve to control the sequencer. For details, see
chapter "Sequencer control funcons". ^ 588
Funcon Info
Select sequence (bit 0) ... Select
sequence (bit 3)
Bit coded selecon of the sequence to be started.
Start sequence The selected sequence is started. The start can take place edge or status-controlled depending on the congu-
raon.
Next sequence step Immediate jump to the next step irrespecve of the me set for the segment.
Pause sequence The sequencer stops in the current step. The expiraon for the me set for the segment is stopped. The
sequencer setpoint remains acve.
Suspend sequence There is a temporal return to the normal setpoint control. The sequence is then connued at the point where
it was suspended.
Stop sequence Direct jump to the end segment. The further execuon depends on the selected end of sequence mode.
Abort sequence Immediate return to the normal setpoint control. The end segment is not executed anymore.
Diagnoscs
For diagnosing the sequencer, the diagnosc parameters listed in chapter "Sequencer diag-
noscs" are available. ^ 134
Internal status signals
The sequencer provides dierent internal status signals (see the following table). These status
signals can be assigned to the relay, the digital outputs or the status word. 4Conguraon of
digital outputs ^ 603
Internal status signal Info
"Sequencer controlled [100]" The control is executed via the sequencer (according to the conguraon of the digital outputs for the current
segment).
"Sequence acve [101]" The sequence is running and is currently not suspended.
"Sequence suspended [102]" The sequence is currently suspended.
"Sequence done [103]" The sequence is completed (end segment was passed through).
Sequencer
505
