Lenze i55AE155F User Manual

t
t
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
0 Hz
30 Hz
10 Hz
20 Hz
40 Hz
50 Hz
60 Hz
-40 Hz
-60 Hz
-50 Hz
-30 Hz
-20 Hz
-10 Hz
t
t
t
t
t
t
t
0x2DDD
Start enableRun
Digital input 2 [12] Start forward (CW)
Digital input 1 [11]
Digital input 3 [13]
Constant TRUE [1]
Stop active [53]
Rotational direction reversed [69]
Running [50]
Output signals
Status signals
Output frequency
Start reverse (CCW)
Enable inverter
Input signals
Frequency setpoint selection
FunctionTrigger
The status signals can be assigned to digital outputs. 4Conguraon of digital outputs ^ 603
①
The "Run" funcons serves as start enable for the funcons "Start forward (CW)" and "Start reverse (CCW)".
Without start enable, the motor cannot be started.
②
If the start command is cancelled, the motor is stopped with the stop method set in 0x2838:003 (P203.03). In the example: Stop with stand-
ard ramp.
③
If, at start enable, "Start forward (CW)" and "Start reverse (CCW)" are already set to TRUE, the motor remains stopped and the inverter
waits for the next valid start edge.
Flexible I/O conguraon
Start / stop motor
Example 2: Start forward/start reverse/stop (edge-controlled)
539
